In industries such as machine tools, textile machinery, food processing, packaging, and industrial automation, equipment demands extreme precision, durability, and the ability to withstand heavy loads. To meet these challenges, Yinhe Transmission introduces its advanced Linear Guide Systems, engineered to deliver maximum rigidity and reliable performance in demanding environments.

Superior Load Capacity and Rigidity

The guide rail and carriages are manufactured with hardened alloy steel, while internal rollers are made from hardened bearing steel. This construction ensures durability under both normal and moment loads, allowing for seamless operation across horizontal, vertical, and cross-axis applications.

Finite-element engineering methods are used to design optimized roller ways, maximizing performance, accuracy, and service life. The result is a linear guide system capable of speeds up to 3 m/s and accelerations up to 50 m/s², making it a robust choice for dynamic, high-load applications.

High Stiffness with Flexible Preload Options

Each carriage includes four recirculating roller circuits that deliver the stiffness essential for precision machining. Engineers can choose between two preload classes:

• P2 (0.08 C) for high stiffness under moderately high loads with intermittent vibration.

• P3 (0.13 C) for maximum stiffness in environments subject to heavy impacts, vibration, and extreme loading.

These preload options provide flexibility to tailor system performance without compromising structural integrity.

Simplified Lubrication and Reliable Protection

The linear guide carriage incorporates four lubrication ports positioned on each side and end, simplifying maintenance while ensuring optimal roller and way lubrication. Built-in microvalves prevent backflow during operation, guaranteeing consistent lubrication even in various orientations.

Additionally, protective gaskets seal the carriage against contaminants, and optional wipers enhance protection for challenging environments. This design ensures long-term stability, reduced downtime, and dependable performance in industrial settings.

Engineered for Demanding Industries

With its combination of superior rigidity, corrosion protection, simplified maintenance, and proven precision, Yinhe Transmission’s Linear Guide Systems are designed to exceed expectations in industries where uptime and accuracy are critical.

For more details about how Yinhe Transmission can optimize your equipment with advanced motion solutions, visit our website: https://yhlinear.com/. Explore the full range of linear motion products built for next-generation automation.
